KW Coilover kit variant 1

Product description

KW V1 BMW F20/F21/F22/F30/F32 - 1022000D

KW V1 1022000D serves several BMW F models, with body style and axle loads defining the correct application. For a matching F20/F21, KW specifies 25–50 mm at the front and 30–55 mm at the rear. The same part number has different application data for the F22, F30 Sedan and F32 Coupe, listed separately below.

Technology and specification

• KW part number: 1022000D.
• Housing: stainless steel (inox-line).
• Damping: preset KW setup.
• Height adjustment: threaded front struts and adjustable rear spring seats with dampers.
• Rear-wheel drive, without electronic damping.
• KW notes that wheel spacers may be required with original wheels.

Application and lowering

Selection and setup

This V1 combines height adjustment with a preset damper characteristic. Check the relevant vehicle row and permitted axle loads before selecting a height within its range. The applications shown are rear-wheel drive without electronic damper control. Do not substitute another vehicle row for a heavier or differently equipped model.
